KEYENCE IM-SERIES

  • 99 dimensions on up to 100 parts
    in seconds
  • No operator subjectivity
  • Automatically collect and generate
    inspection reports
IM lowered ring light (green)

  • WHAT IS THE IM?

    The IM-Series Instant Measurement System is a visual inspection system that performs measurements in place of optical comparators, calipers/micrometers, measuring microscopes, and optical CMMs.

  • WHY DO PEOPLE USE THE IM?

    Conventional 2D measurement tools are time-consuming and difficult to use. The IM Series drastically reduces inspection time and removes all operator subjectivity.

  • WHAT DO PEOPLE MEASURE?

    Common applications are: springs, stamped parts, plastics, rings, gears, bottles, blind holes, threads, and more.

  • WHAT MAKES THE IM SERIES UNIQUE?

    Perform hundreds of measurements on parts in seconds with an accuracy of +/- 2um. Profiles, GD&T, CAD imports, and automated programming are all easily performed.

  • Springs

  • Lathe Processing

  • Threads

  • Gears

  • Plastic with Toplight

SAME DAY SHIPPING DIRECT SUPPORT DIRECT SALES

WHY KEYENCE?

KEYENCE has been an industry leader in sensing technology since 1974. KEYENCE's direct sales team visits customers with live demo equipment to find the best possible solution for all applications.

Learn more about the IM-Series Instant Measurement System!
